【資料名稱】： 基站告警

【資料作者】：NOKIA

【資料日期】：2005

【資料語言】：中文

【資料格式】：PDF

【資料目錄和簡(jiǎn)介】：

UltraSite EDGE BTS alarms

Contents
1 Statutory statements 7
1.1 CE Marking 7
1.2 FCC Statement 8
2 Alarm handling 9
2.1 Nokia UltraSite EDGE Base Station alarm examples 9
2.2 Identifying faulty units 10
2.3 Troubleshooting 12
2.4 Nokia UltraSite EDGE Base Station alarm reclassification 13
2.5 Nokia UltraSite EDGE Base Station alarm table 16
3 Alarms for UltraSite EDGE BTS 19
3.1 Alarms list for UltraSite EDGE BTS 19
3.2 7208 LOCAL BLOCK 20
3.3 7401-7424 EXTERNAL ALARM 21
3.4 7600 BCF FAULTY 21
3.5 7601 BCF OPERATION DEGRADED 22
3.6 7602 BCF NOTIFICATION 24
3.7 7603 BTS FAULTY 27
3.8 7604 BTS OPERATION DEGRADED 28
3.9 7605 BTS NOTIFICATION 29
3.10 7606 TRX FAULTY 30
3.11 7607 TRX OPERATION DEGRADED 35
3.12 7608 TRX NOTIFICATION 39
3.13 7609 TRE FAULTY 40
3.14 7612 SITE POWERING FAULTY 40
3.15 7613 SITE POWERING OPERATION DEGRADED 41
3.16 7614 SITE POWERING NOTIFICATION 41
3.17 7615 RTS IN TEST USE 42
3.18 7616 OSCILLATOR ADJUSTMENT TEMPORARILY INTERRUPTED 43
3.19 7617 SEVERAL CALLS DROPPED DUE TO PROBLEM WITH
TRANSCODER 43
3.20 7622 CABINET OPEN 44
3.21 7801 MMI CONNECTED TO BASE STATION 44
3.22 7995 MAINS BREAKDOWN WITH BATTERY BACKUP 45
4 Transmission unit alarms 47
4.1 Alarm list for ITN-related transmission products 47
4.2 Monitoring transmission node alarms 48
5 Common node alarms 57
5.1 20 Blocked from use 57
5.2 62 No connection 57
5.3 112 Frequency error 58
5.4 122 Synchronizing fault 59
5.5 124 Synchronising fault in clock recovery 59
5.6 125 Loss of synchronisation signals 60
5.7 139 Subrack is missing units 61
5.8 140 Subrack has excessive units 62
5.9 142 Fault in installation of equipment 62
5.10 162 Database full 63
5.11 221 Version mismatch 63
5.12 240 Active alarm point 64
6 Common alarms for FXC transmission units 67
6.1 21 Loop to interface 67
6.2 22 Loop to equipment 68
6.3 25 Test generator on 69
6.4 32 Loss of outgoing signal 69
6.5 50 Loss of incoming 2M signal 70
6.6 66 AIS 2M 70
6.7 81 Loss of frame alignment 71
6.8 86 Loss of CRC multiframe alignment 73
6.9 99 Error rate > 1 E-3 73
6.10 102 Error rate > 1 E-6 75
6.11 137 Fault in oscillator 75
6.12 148 Equipment reset 76
6.13 150 Fault in unit 76
6.14 179 Far-end alarm 77
7 Specific alarms for FXC E1/T1 transmission units 79
7.1 56 Loss of incoming 1.5M signal 79
7.2 73 AIS 1.5M 79
7.3 172 Yellow alarm 80
8 Specific alarms for FXC RRI transmission units 81
8.1 64 Alarm signal received 81
8.2 128 Fault in equipment 81
8.3 141 Forced control on 82
8.4 143 Fault in changeover function 83
9 Specific alarms for FXC STM transmission units 85
9.1 124 Synchronisation fault in clock recovery 85
9.2 125 Loss of synchronization signal(s) 85
9.3 126 Unit function degraded 86
9.4 139 Subrack is missing units 87
9.5 140 Subrack has excessive units 87
9.6 141 Forced control on 88
9.7 152 Fault in block 88
9.8 162 Database full 89
9.9 165 Real time lost fault 89
9.10 184 Real time updated 90
9.11 207 Calibration expired 91
9.12 221 Version mismatch 91
9.13 223 Protection switch 92
10 Specific alarms for FXC STM-1 93
10.1 148 Equipment reset 93
10.2 149 Forced indication 93
10.3 150 Fault in unit 94
10.4 162 Database full 94
11 Specific alarms for FXC STM-1 Interface x 97
11.1 23 Test mode active 97
11.2 48 Loss of incoming signal 98
11.3 57 Loss of pointer 98
11.4 59 Incoming signal level incorrect 99
11.5 64 Alarm signal is received 100
11.6 81 Loss of frame alignment 101
11.7 141 Forced control on 102
11.8 153 Fault in transmitter 102
11.9 156 Laser power out of range 103
11.10 158 Forced laser cut off 104
11.11 162 Database full 105
11.12 213 Remote Defect Indication (RDI) 105
11.13 214 Signal degraded 106
11.14 215 Trace identifier mismatch 107
12 Specific alarms for FXC STM-1 Interface S4 x 109
12.1 47 Payload mismatch 109
12.2 57 Loss of pointer 110
12.3 64 Alarm signal is received 110
12.4 82 Loss of multiframe alignment 111
12.5 162 Database full 112
12.6 213 Remote Defect Indication (RDI) 112
12.7 214 Signal degraded 113
12.8 215 Trace identifier mismatch 114
12.9 216 Unequipped signal 115
13 Specific alarms for FXC Bridge PDH 117
13.1 22 Loop to equipment 117
13.2 32 Loss of outgoing signal 117
13.3 126 Unit function degraded 118
13.4 139 Subrack is missing a unit 118
13.5 145 Temperature error 119
13.6 221 Version mismatch 119
14 Specific alarms for FXC Bridge SDH 121
14.1 22 Loop to equipment 121
14.2 47 Payload mismatch 121
14.3 64 Alarm signal is received 122
14.4 81 Loss of frame alignment 123
14.5 96 Excessive error rate 123
14.6 148 Equipment reset 124
14.7 162 Database full 125
14.8 213 Remote defect indication (RDI) 125
14.9 214 Signal degraded 126
14.10 215 Trace identifier mismatch 127
14.11 216 Unequipped signal 128
15 Alarms for UltraSite EDGE BTS with WCDMA upgrade 129
